RAM is one of those upgrades everyone seems to skimp on when buying a
PC, only to later wish for more. Regretting your underpowered memory
purchase? Here’s how to speed up your machine by installing some
additional memory.
Memory is often one the critical bottlenecks on a PC, so faster,
larger stores of RAM can go a long way to making your PC perform better
and with more stability. It’s not hard, even for beginner geeks. Crack
open that PC in today’s hardware upgrade!
Identifying and Buying Your New RAM (The Hard Part)
Your RAM is likely installed in these slots on your motherboard,
called the DIMM slots. This motherboard has room for six sticks of
memory. Note the pins and how the RAM lines up with them—important to
note to install properly. The median is off center to show you clearly
which direction to orient them. If you’re strong, you can probably force
them in backwards, but computers don’t really respond well to that kind
of bullying.
Each motherboard has specific requirements for RAM. Sometimes you can
install slightly different kinds of RAM, but this could result in
decreased performance or even shorter life for your new memory. If at
all possible, install memory best suited to your mainboard, meeting as
many of the following requirements as possible:
- Timing
- Speed/Data Rate
- Voltage
- Number of Pins (Mandatory)
- Maximum supported memory
- Maximum supported memory per DIMM slot
- Does your mainboard require memory in pairs or not?
While all the specs for your RAM are important, the number of pins
are probably the first thing you should look at. There are going to be
multiple references to the number of these pins—you can clearly see the
comparison of them here, above. Note that depending on the type of RAM,
including speed/data rate, a stick may have more or fewer pins, and will
have the notch or notches in different locations. Your motherboard is
only going to take RAM with only one kind of pin count. Again, you can
probably force it in, but it will probably be the end of your PC!
While installing additional or all-new memory is not terribly
complicated, even for a beginner geek, buying the proper memory can be a
frustrating challenge. If you are confused, you can check out our
easy beginner-friendly guide to buying memory. Here you can figure out these confusing requirements your motherboard has and buy the right RAM for your system.
Brands of RAM do matter, especially to geeks. HTG doesn’t endorse any
particular brand, although certain authors do have their favorites. If
you have had good (
or even terribly bad!) experiences with certain manufacturers, tell us about them in the comments.
Installing RAM in Your PC (The Easy Part!)
Every mainboard has nitpicky requirements for the settings of the
RAM, but almost every machine has RAM installed the same way. DIMM slots
have latches on either side that both lock in and release RAM from the
pins they’re seated on to function. Let’s take a look at one very easy
installation of RAM.
With your PC case open you won’t need any tools but your bare hands. (If you don’t know how to open your PC,
check here for detailed directions.) Wearing gloves is generally not a good idea. And if your PC is not
powered down and unplugged, you run the risk of hurting yourself or your equipment.
This particular PC has RAM on risers, which are installed in special
DIMM slots (DIMM slot-like, actually) on the mainboard. Your technique
for installing into mainboard DIMM slots will most likely be nearly
identical to this—in fact it will have even fewer steps.
(Author’s Note: With every installation of RAM or any PC
component, you’re going to want to stay grounded so that the static
electricity from your body doesn’t flow into your new memory, or parts
of your PC. While these parts are very sensitive, I have personally never had problems with static, only with foolishly installing things the wrong way. It is, however, best practice to stay grounded the entire time and not remove your parts and install them on a separate surface. Installing
RAM on these risers, with the parts removed, was more clear and more
easy to photograph and the fundamentals are exactly the same of
installing in a PC mainboard. Just remember your PC may look more
similar to the first examples, rather than this one. And, as in any
hardware upgrade, keep in mind that you can run the risk of damaging
your equipment. Keeping all that in mind, understand that installing RAM
is actually quite easy.)
We can see the DIMM slots each holding a stick of RAM, very similar
to the ones on your mainboard. Always remember that your memory is very
sensitive to static shock, and be careful to ground yourself and work on
the most non-conductive, non-static surface available–your floor or
carpet are not acceptable surfaces!
To remove a stick of memory from a DIMM slot, gently push down on the
tabs on either side in tandem. Don’t force it, but apply firm pressure
as needed. Your memory should begin to pop free from inside the DIMM
slot. If it doesn’t come free easily, rock it gently back and forth from
the sides to remove it. Above all, be gentle, as damage to the DIMM
slot could ensure that your PC will never work properly again!
Handle the stick of RAM by the sides as shown, touching as little of
it as possible. You want to keep your fingerprints and hand oils off of
your new memory. Sit the old RAM aside on an anti-static surface and
find your new RAM for installation.
With your DIMM slot tabs open, line up the pins and firmly (but not
roughly) press on the outside of the stick of RAM to install. If the RAM
is seated properly, the pressure from you pressing in the RAM will
actually begin to snap the DIMM slot tabs shut, locking the new RAM in
place. Make sure that the tabs are locked into the notches on the side
of the RAM.
You also may need to install your memory in pairs. If this is the
case, you will probably have to buy your memory in kits—pairs of RAM
meant to be installed together. Make sure you do this!
In our example, we return our risers to our mainboard spot, adding the additional steps most HTG readers won’t have to face.
And that’s pretty much all there is to installing RAM! Again, your PC
may not have the risers shown before, but installing memory in the DIMM
slot as shown above is similar in all cases—a DIMM slot is a DIMM slot,
pretty much. The techniques and best practices for removing and
installing new RAM will be the same no matter what device you install
into. Just stay cautious of static, don’t be too rough with your parts,
and you’ll be on your way to speeding up your PC’s performance in no
time.
